number after power up. The
default is disabled.
Fan Speed Demanded
Speed of the combustion air
blower in rpm
400103
nvoFnSpdDem_XXX
SNVT_count_f
Fan Speed Feedback
Speed of the combustion air
blower in rpm
400104
nvoFnSpdFdbk_XXX
SNVT_count_f
Flame Signal
0-100%
400101
nvoFlmSig_XXX
SNVT_lev_percen
t
Burner Control State
1 Self Check
2 Standby
3 Waiting for Limit to close
4 Prepurge
5 Direct Burner Ignition
6 Low Fire Hold
7 Calibration
8 Rate Limit
9 Run (Modulate)
10 Postpurge
11 Pump Purge
12 Standby Delay
13 Lockout
14 Boiler Switch Off
15 Warm Wheather Shutdown
400013
nvoBrnCtrlSt_XXX
SNVT_count_f
Burner Run Time
Hours
Hours (U32)
400024-
25
nvoBrnRnTmHr_XXX
SNVT_time_hour
Burner Cycle Count
0-999,999 (U32)
400026-
27
nvoBrnCycCnt_XXX
SNVT_count_f
Pump A (System
Pump) Cycles
0-999,999 (U32)
400686-
687
nvoPmpACyc_XXX
SNVT_count_f
Pump B (Boiler Pump)
Cycles
0-999,999 (U32)
400688-
689
nvoPmpBCyc_XXX
SNVT_count_f
Pump C (DHW Pump)
Cycles
0-999,999 (U32)
400690-
691
nvoPmpCCyc_XXX
SNVT_count_f
Pump A (System
Pump) Status
0 = Off, 1 = On
400106
nvoPmpAStat_XXX
SNVT_switch
Pump B (Boiler Pump)
Status
0 = Off, 1 = On
400107
nvoPmpBStat_XXX
SNVT_switch
Pump C (DHW Pump)
Status
0 = Off, 1 = On
400108
nvoPmpCStat_XXX
SNVT_switch
Recirculation
Temperature
-40°F (-40°C) to 320°F (160°C)
400038
nvoRecrcTmp_XXX
SNVT_count_f
