LED status Operating state
green:
yellow:
red:
Missing grid
Indicates lack of grid voltage. This condition does not allow the inverter to
connect to the grid.
green:
yellow:
red:
Warning indication: (W message codes) or Error: (E message codes)
- Indicates that the inverter control system has detected a warning (W) or error
(E). It is possible to identify the type of problem generated in the dedicated
section of Web User Interface (“INVERTER LOG menu” section).
green:
yellow:
red:
Temperature protection trip
Indicates that the trip relating to internal temperatures (insufficient or
excessive temperature) may have been activated.
green:
yellow:
red:
Ventilation anomaly
Indicates ananomaly in the operation of the internal ventilation system that
could limit output power at high ambient temperatures.
Overvoltage surge arresters triggered (where fitted)
Indicates that any class II overvoltage surge arresters installed on the AC or
DC side have been triggered.
Internal statistics memory anomaly
Indicates an operating anomaly in the internal memory on which the inverter
statistics are stored.
Buffer battery discharged
The buffer battery is low and the inverter does not maintain the time setting.
green:
yellow:
red:
Pre-commissioning phase (first start-up of inverter)
The commissioning of the inverter must be completed through the Installation
wizard steps (Web User Interface) or using the FIMER Installer for Solar
Inverters mobile APP.
Initial configuration failure
The inverter is in locked state due to a failure in the initial configuration of the
equipment, such as the standard network setting for the country of installation.
Incompatibility of the device firmware versions
The firmware versions of the various devices comprising the equipment are
incompatible and are being updated (this is an automatic operation).
Temperature sensor anomaly detected
green:
yellow:
red:
Remote OFF activated
The Remote Off command has been activated.
The unit will not connect to the network until the remote ON command has
been activated.
green:
yellow:
red:
Anomaly in the insulation system of the photovoltaic generator
Indicates that a leakage to ground from the PV generator has been detected,
causing the inverter to disconnect from the grid.
green
yellow
Anti-PID function is ON: Inverter is providing Anti-PID functionality
green
yellow
red
DC arc fault detected during operation
If a DC arc fault is detected during operation, the inverter disconnects from AC
grid (the error code is readable through internal Webserver).
green
yellow
red
AFD board self test failure
Potential problem on the AFD board detected during self test phase
The following table shows all the possible status of “WLAN/LAN” LED on the LED panel (08) according
to the operating status of the wireless or ethernet communication lines.
