FIMER_PVS-175-TL A.1 Version_Product manual_EN_RevC-
F
28
PVS-175-TL
Insulation Level Transformerless
Marking CE
(4)
Safety, EMC and Radio Spectrum Standards
IEC/EN 62109-1, IEC/EN 62109-2,
EN 61000-6-2, EN 61000-6-4,
EN 61000-3-11, EN 61000-3-12,
EN 301 489-1, EN 301 489-17,
EN 300 328, EN 62311
Grid standard
(check the availability with your sales channel)
CEI 0-16, UTE C 15 712-1,
JORDAN IRR-DCC-MV, BDEW,
P.O. 12.3, DRRG D.4
Accessories
Assembly accessories
PVS-175 Installation Kit
AC multicore cable gland plate
(Supports M63 Ø 37…53mm + M32 Ø
18...25mm)
DC Series Arc Fault Circuit Interrupter
Type I acc. to UL 1699B
(5)
with single-
MPPT sensing capability
DC link recharge circuit
(6)
Night time operation with restart
capability
Anti-PID
(7)
Based on night time polarization of the
array
1. In the event of a fault, limited by the external protection envisaged on the AC circuit
2. According to standard IEC60947.3 Table D.5
3. The AC voltage and frequency range may vary depending on specific country grid standard
4.
Hereby, Power-One Italy S.p.A. (A Member of the FIMER Group) declares that the radio
equipments (radio module combined with the inverter), to which this user manual refers, are in
compliance with the Directive 2014/53/EU. The full text of the EU Declaration of Conformity is
available at the following internet address: www.fimer.com
5. Performance in line with the relevant requirements of the Draft IEC 63027 standard
6.
The Inverter cannot verify the photovoltaic array isolation resistance before connection during
Night time. When this accessory is present, the inverter must be installed and operate in “restricted
areas (access limited to qualified personnel)” according to IEC 62109-2
7. Cannot operate simultaneously with the Night Mode
NOTE – D Features not specifically mentioned in this data sheet are not included in the
product.
NOTE – D The technical data provided in this manual does not substitute the data supplied
on the labels affixed to the equipment.
Tightening torques
To maintain the IP65 protection degree of the system and for correct installation, the following torques
must be applied:
Tightening torques
Single core AC cable gland (11) M40 5 Nm
PE cable gland (12) M32 5 Nm
Multi core AC cable gland (11) M63
100 Nm
Signal cable gland (13) PG16 5 Nm
Signal cable gland (13) PG21 7.5 Nm
AC connection busbar (27) bolts 25 Nm
Protective earth point (int.) (28) nut 21 Nm
Protective earth point (ext.) (10) bolt 15.2 Nm
Junction screws (20) 12 Nm
Side bracket screws 5 Nm
AC interface connection point bolts (34) (Phases) 4 Nm
