PVS-175-TL
AC Connections Type
Busbar for lug connections with M10 bolts
(included);
Single core cable gland plate with 4 individual
AC cable glands: 3 x M40: Ø 22...32mm, 1 x
M32: Ø 18...25mm
Multi core cable gland plate (optional) with 2
individual AC cable glands: 1 x M63: Ø
37…53mm, 1x M32 Ø 18...25mm)
Output protection
Anti-islanding Protection According to local standard
Maximum external AC overcurrent protection 200 A
Output overvoltage protection -Modular surge arresters Type 2
Operating performance
Maximum Efficiency (ηmax) 98.7%
Weighted Efficiency (EURO) 98.4%
Communication
Communication interfaces
1x RS485, 2x Ethernet (RJ45), WLAN
(IEEE802.11 b/g/n @ 2,4 GHz)
Local user interface
4 LEDs, Web User Interface, Mobile
APP
Communication protocol Modbus RTU/TCP (Sunspec compliant)
Commissioning tool
FIMER Installer for solar inverters
mobile app / Embedded Web User
Interface
Remote monitoring services
Aurora Vision(R) Plant Management
Platform
Advanced features
Built-in Export Limitation control
algorithm/ Integrated data logging for
inverters and accessories / Remote FW
update
Environmental
Ambient temperature range
-25...+60°C /-13...140°F with derating
above 40°C / 104 °F
Storage temperature -40°C...+85°C / -40°F...185°F
Relative Humidity 4…100 % with condensation
Typical noise emission pressure 65 dB(A) @ 1 m
Maximum operating altitude without derating 2000 m / 6560 ft
Environmental pollution degree
classification for external environments
3
Environmental class Outdoor
Climatic category according to IEC 60721-3-4 4K4H
Physical
Environmental Protection Rating IP 65 (IP54 for the cooling section)
Cooling System Forced air
Dimensions (H x W x D)
867x1086x419 mm / 34.2”x42.7”x16.5” for
-SX model
867x1086x458 mm / 34.2”x42.7”x18.0” for
-SX2 model
Weight
~76 kg / 167,5 lbs for power module ;
~77 kg / 169,7 lbs for Wiring box
Overall max ~153 kg / 337,2 lbs
Assembly System Mounting bracket support
Overvoltage rating as per IEC 62109-1 II (DC input) III (AC output)
Safety
Safety class I
