LED status Operating state
Blue:
Wireless not configured or/and ethernet cable not connected.
Blue:
Scanning for available wireless networks.
Blue:
Trying to connect to a wireless network.
Blue:
Wireless or ethernet network is connected to the inverter and IP address is
obtained.
Connection to Web User Interface
The inverter is equipped with an advanced integrated Web User Interface that allow a full access to
all configuration and comissioning parameters from any electronic device (laptop, tablet and
smartphone).
Access to the Web User Interface
To access to the Web User Interface is required to connect a device equipped with wireless connection
(such as tablet, laptop or smartphone).
Depending on the connection method choosen during the inverter commissioning phase (“Station
Mode” or “AP Mode”) it’s required to follow one of the two procedures described below:
Connection to the inverter in “Station Mode”
• Enable the wireless connection on the device (tablet, smartphone or laptop) and connect it to the
same wireless network to which the inverter is connected.
•
Open an internet browser (recommended browser: Chrome versions from v.55, Firefox versions
from v.50) and enter the links (corresponding to the IP Address assigned by the router to the inverter,
or the “Host Name”) provided during the commissioning phase to access the login page.
NOTE – D In order to use the “Host Name” as an alternative to the dynamic IP address, the
Wi-Fi router to which the inverter is connected (when operating in “Station Mode”) must
provide the Domain Name System (DNS) service (contact the network administrator for
further information regarding the presence or absence of the DNS service in the Wi-Fi
router or how to enable it). In this way, even if the IP address assigned to the inverter should
change over time (dynamic IP), it will always be possible to use the same “Host Name”
which will remain unchanged over time.
NOTE – D The IP address assigned may vary for reasons connected to the wireless router
setup (for example, a very brief DHCP lease time). If verification of the address is required,
it is usually possible to obtain the client list (and the corresponding IP addresses) from the
wireless router administration panel.
NOTE – D If the “Host Name” was lost, it could be obtained writing this url:
http://ABB-XX-XX-XX-XX-XX-XX.local
replacing the “X” with the hex digits of the MAC address of the inverter (it can be found on
the “Communication Identification label” placed on the side of the inverter or applied during
the commissioning phase to the plant documentation).
