Installations of IP65 protection covers for wiring box
openings
WARNING – B Some wiring box parts may be subject to hazardous voltages for the operator.
Before performing any work on the inverter, refer to “Inverter total de-energization and
safe access” paragraph on this manual to know all the necessary step to safely operate
on the inverter.
ATTENTION – A Never leave the power module (01) or the wiring box (02) disassembled on
the field.
In case is necessary to install the wiring box (02) only, protection covers for wiring box openings kit
is available as accessory options.
To install the protection covers place them over the wiring box openings and fix it using the 8 x M5
screws provided with the accessory kit.
