Fischer Panda 18 - Installation with Looped-In AC-Control Box

Installation Instructions
Seite/Page 108 - Kaptitel/Chapter 6: Installation Instructions 18.12.15
Fig. 6.16-1: AC-Control box - example
6.16.1 Installation with looped-in AC-Control box
All electrical safety installations have to be made on board (RCD etc.).
3
2
1
1. Terminal block for excitation
2. Boost solenoid
3. Capacitors
