Fischer Panda 18 - Checking the Water Separator in the Fuel Supply; Replace the Air Filter Mat

Maintenance Instructions
18.12.15 Kapitel/Chapter 7: Maintenance Instructions - Seite/Page 147
7.14 Checking the water separator in the fuel supply
Fig. 7.14-1: Pre-filter with water separatorThe pre-filter with water separator has a cock underneath, by
which means the water can be drained.
This water sinks to the bottom, due to the difference in the
densities of water and fuel. Water is heavier than the diesel
Sample picture
7.14.1 Replace the air filter mat
Fig. 7.14-1: Air suction housing1. Open the air suction housing by loosen the six screws on
the housing cover.
Use spanner size 8 mm.
Fig. 7.14-2: Opened air suction housing2. Change the air filter mat.
3. Close the suction air housing.
