Installation Instructions
18.12.15 Kapitel/Chapter 6: Installation Instructions - Seite/Page 97
Fig. 6.12.1-2: Example for an unfavourable Installation
6.13 Fuel system installation
6.13.1 Fischer Panda installation kit - Fuel system
Note:The following additional components will be required for
the specified installation. You can purchase them as an
installation kit or separately at Fischer Panda.
Fig. 6.13.1-1: Fuel hoseFuel hose
representative picture
Example of an unfavourable installation:
- Water lock not far enough below the lowest level of the generator
- Distance water lock to exhaust/water separator too large
