Maintenance Instructions
Seite/Page 154 - Kaptitel/Chapter 7: Maintenance Instructions 18.12.15
Fig. 7.14.5-3: Alternator3. The alternator must be pressed in the direction of the
thermostat housing.
4. Exchange the V-belt.
Sample Picture
Fig. 7.14.5-4: V-belt5. Afterwards, the V-belt must be tightened again.
6. The V-belt must be tightened in such a way, that it is
possible to press it about approx. 10 mm.
7. Tighten the screws above and underneath the alternator.
Sample picture
7.15 The raw water circuit
7.15.1 Clean raw water filter
