The Panda Generator
18.12.15 Kapitel/Chapter 4: The Panda Generator - Seite/Page 45
4.3 Details of functional units
4.3.1 xControl panel
The control panel is fitted with various monitoring functions, which increase functional reliability and operating safety
of the generator. Various parts of the generator are monitored with sensors which, when triggered, generate an error
message and can shut down generator operation under certain circumstances to prevent damage.
Fig. 4.3-1: xControl CP-G Front Side
Fig. 4.3.1-2: xControl CP-G Reverse Sidel
Notice!:See xControl manual for details!
