Tables
Seite/Page 200 - Kaptitel/Chapter 9: Tables 18.12.15
³ 0,35l/kW electrical power, the randomized values between 30% and 80% of
the rated speed
9.2 Rated current
Fig. 9.2-1: Rated current
9.3 Cable cross section
Fig. 9.3.0-1: Cable cross section
Rated speed 2700 rpm
Idle running speed 1600 rpm
Valve clearance (engine cold) 0,18 - 0,22 mm
Cylinder head nut torque 93,1 - 98 Nm
Compression ratio
Lubrication oil capacity 9,5 l
Fuel consumption ³ approx. 1,95 - 5,2l
Oil consumption max. 1% of fuel consumption
Oil specification API CF
Cooling water requirement for seawater
circuit (Marine generators only)
55‐80 l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12V 136Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
70mm²
Max. exhaust back pressure 10,7 kPa
107 Millibar
Panda 45i
Panda 8000 - 230 V / 50 Hz
Panda 8000 - 400 V / 50 Hz
Panda 8000 - 120 V / 60 Hz
27,0 A
8,3 A
61,8 A
Panda 18 - 230 V / 50 Hz
Panda 18 - 400 V / 50 Hz
Panda 18 - 120 V / 60 Hz
60,3 A
20,0 A
128,0 A
Panda 9000 - 230 V / 50 Hz
Panda 9000 - 400 V / 50 Hz
Panda 9000 - 120 V / 60 Hz
34,9 A
11,1 A
74,5 A
Panda 24 - 230 V / 50 Hz
Panda 24 - 400 V / 50 Hz
Panda 24 - 120 V / 60 Hz
89,1 A
30,1 A
161,1 A
Panda 12000 - 230 V / 50 Hz
Panda 12000 - 400 V / 50 Hz
Panda 12000 - 120 V / 60 Hz
41,7 A
13,7 A
89,0 A
Panda 30 - 230 V / 50 Hz
Panda 30 - 400 V / 50 Hz
Panda 30 - 120 V / 60 Hz
Anfrage
35 A
219 A
Panda 14000 - 230 V / 50 Hz
Panda 14000 - 400 V / 50 Hz
Panda 14000 - 120 V / 60 Hz
48,0 A
15,2 A
112,7 A
length 1 - 3 m 4 - 6 m 7 - 10 m 11 - 15 m 16 - 20 m
16 mm² 70 A 63 A 55 A 48 A 42 A
25mm² 112 A 100 A 88 A 75 A 63 A
35mm² 145 A 130 110 100 A 90 A
50mm² 225 A 200 A 175 A 150 A 125 A
