Fischer Panda 18 - Page 199

Tables
18.12.15 Kapitel/Chapter 9: Tables - Seite/Page 199
² progressive speed by VCS
³ 0,35l/kW electrical power, the randomized values between 30% and 80% of
the rated speed
Fig. 9.1-7: Technical Data igenerators
³ 0,35l/kW electrical power, the randomized values between 30% and 80% of
the rated speed
Fig. 9.1-8: Technical Data igenerators
Recommend cable cross size starter battery
cable
Length 4 meter max.
70mm² 70mm² 70mm² 70mm²
Max. exhaust back pressure 4 kPa
40 Millibar
10,7 kPa
107 Millibar
10,7 kPa
107 Millibar
10,7 kPa
107 Millibar
Panda 30/4 Panda 30/4 Panda 40/4 Panda 50/4 Panda 70/4
Panda 5000i Panda 8000i Panda 10000i Panda 15000i Panda 25i
Type EA300 Z482 Z602 D902 Kubota V1505
Governor iControl2 iControl2 iControl2 iControl2 iControl2
Automatic start booster no no no no no
Cylinder 12234
Bore 75mm 67mm 72 mm 72mm 78mm
Stroke 70mm 68mm 73,6 mm 73,6mm 78,4mm
Stroke volume 309cm
3
479cm³ 599cm³ 898cm³ 1498cm
3
Max. power (DIN 6271-NB) at 3000rpm 5,1kW 9,32kW 11,6kW 17,5kW 23,3kW
Rated speed 3000rpm 3000rpm 3000rpm 3000UpM 1500 rpm
Idle running speed 2900rpm 2900rpm 3100rpm 2900UpM 1800 rpm
Valve clearance (engine cold) 0,16 - 0,20mm 0,2mm 0,2mm 0,2mm 0,2mm
Cylinder head nut torque 58,8 - 63,7Nm 42Nm 42Nm 42mm 68Nm
Compression ratio -- 23:1 24:1 24:1 22:1
Lubrication oil capacity 1,3l 2,8l 2,8l 3,7l 6,0l
Fuel consumption ³ approx. 0,42 -
1,12l
approx. 0,7-1,8l approx. 1,0-2,66l approx. 1,3-3,6l approx. 1,20-3,36l
Oil consumption max. 1% of fuel consumption
Oil specification API CF API CF API CF API CF API CF
Cooling water requirement for seawater
circuit (Marine generators only)
-- 16-28l/min 16-28l/min 16-28l/min 28-40l/min
Permissible max. permanent tilt of engine a) 25° crosswise to the longitudinal axis
b) 20° in longitudinal direction
Recommend starter battery size 12V 28Ah
equivalent
12V 28Ah
equivalent
12V 36Ah
equivalent
12V 52Ah
equivalent
12V 70Ah
equivalent
Recommend cable cross size starter battery
cable
Length 4 meter max.
25mm² 25mm² 25mm² 25mm² 25mm²
Max. exhaust back pressure -- 9,3 kPa
93 Millibar²
9,3 kPa
93 Millibar
9,3 kPa
93 Millibar²
10,7 kPa
107 Millibar
Panda 45i
Type Kubota V2403
Governor VCS
Automatic start booster no
Cylinder 4
Bore 87 mm
Stroke 102,4 mm
Stroke volume 2434 ccm
Max. power (DIN 6271-NB) at 3000rpm 31,1 kW
