Fischer Panda 18 - Replacement of the Impeller

Maintenance Instructions
Seite/Page 156 - Kaptitel/Chapter 7: Maintenance Instructions 18.12.15
7.16.1 Replacement of the impeller
Fig. 7.16.1-1: Raw water cockClose the raw water stop cock.
Representative picture
Fig. 7.16.1-2: Raw water pumpRaw water pump on the front side of the genset.
Representative picture
Fig. 7.16.1-3: Cover raw water pumpRemove the cover of the raw water pump by loosen the
screws from the housing.
Representative picture
