Fischer Panda 18 - Diameter of Conduits

Tables
18.12.15 Kapitel/Chapter 9: Tables - Seite/Page 207
If your generator is not mentioned, ask your local Fischer Panda Dealer for
the technical datas coil.
9.10 Diameter of conduits
Fig. 9.10-1: Diameter of conduits
9.11
Generator type Ø Cooling water conduit Ø Exhaust conduit
[mm]
Ø Fuel conduit
Freshwater
[mm]
Seawater
[mm]
Supply
[mm]
Return
[mm]
Panda PMS 3,8 ND 12 12 30 8 8
Panda PMS 4,5 ND 12 12 30 8 8
Panda PMS 4500 SCB 12 12 30 8 8
Panda PMS 5000 SCE 12 12 30 8 8
Panda PMS 4500 FCB 12 12 30 8 8
Panda PMS 5000 LPE 16 16 30 8 8
Panda PMS 6000 ND 20 20 40 8 8
Panda PMS 8000 NE (8 mini
Digital)
20 20 40 8 8
Panda PMS 9000 ND 20 20 40 8 8
Panda PMS 12000 NE (12 mini
Digital)
20 20 40 8 8
15 mini Digital 20 20 40 8 8
Panda PMS 14000 NE 20 20 40 8 8
Panda PMS 18 NE (16 Digital) 25 20 50 8 8
Panda PMS 24 NE (22/25 Digital) 25 20 50 8 8
Panda PMS 30 NE 25 20 50 8 8
Panda PMS 33 KU 30 25 50 8 8
Panda PMS 42 KU 30 30 50 8 8
Panda PMS 32 YA 30 30 50 8 8
Panda PMS 50 YA 30 30 60 8 8
Panda PMS 60 YA --60 88
Panda PMS 50 MB 40 30 60 8 8
Panda PMS 60 MB 40 40 60 8 8
Panda PMS 75 MB 40 30 60 8 8
Panda PMS-HD 7,5-4 KU 25 20 40 8 8
Panda PMS-HD 09-4 KU 25 20 50 8 8
Panda PMS-HD 12-4 KU 25 20 50 8 8
Panda PMS-HD 17-4 KU 25 25 60 8 8
Panda PMS-HD 22-4 KU 30 30 60 8 8
Panda PMS-HD 30-4 KU 30 30 60 8 8
Panda PMS-HD 40-4 KU 30 30 60 8 8
Panda PMS-HD 60-4 DZ --- --
Panda PMS-HD 70-4 DZ --- --
Panda PMS-HD 85-4 DZ --- --
Panda PMS-HD 110-4 DZ --- --
Panda PMS-HD 130-4 DZ --- --
