Fischer Panda 18 - The Following Items Need to be Installed

Installation Instructions
18.12.15 Kapitel/Chapter 6: Installation Instructions - Seite/Page 99
Fig. 6.13.1-5: Quick connector for fuel linesQuick connector for fuel lines
representative picture
Fig. 6.13.1-6: Hose clampsHose clamps
representative picture
6.13.1.1 The following items need to be installed:
• Fuel supply pump (DC)
• Pre-filter with water separator (not part of the delivery)
• Fine particle fuel filter
• Return fuel line to fuel tank (unpressurized)
The external Fuel pump should be installed near the tank
Fig. 6.13.1-1: electrical fuel pumpElectrical fuel pump
With the Fischer Panda generator is usually supplied an
external, electrical fuel pump (DC). The fuel pump must be
installed close at the fuel tank. The electrical connections is
prepared at the generator.
Some generators (f.e. with Deutz diesel engine) has an
engine driven internal fuel pump. At these generators the
electrical fuel pump is optional.
