Fischer Panda 18 - Demounting the Cooling Disc (if Existent); Demounting the Backend Bearing

Maintenance Instructions
Seite/Page 124 - Kaptitel/Chapter 7: Maintenance Instructions 18.12.15
7.10.1.1 Demounting the cooling disc (if existent)
Fig. 7.10.1.1-1: Demounting the cooling discTo demount the cooling disc, detach the cooling discs’
holding nut and take off the disc.
Sample Picture
7.10.1.2 Demounting the backend bearing
Fig. 7.10.1.2-1: Marking the bearing cover.Degrease the spot with a fat solvent as shown, apply
markings with a waterproof pen.
Sample Picture
