Basics
Seite/Page 32 - Kaptitel/Chapter 3: Basics 18.12.15
Fig. 3.3-6: Manual6. Fischer Panda manual
The Fischer Panda manual comprises the following
components:
a.- Transparent envelope with general information, war-
ranty terms, installation certificates, and service list.
b.- Generator manual
c.- Spare parts catalogue „Installation & Service Guide“
d.- Engine manual from the engine manufacturer
e.- Generator circuit diagram
representative picture
3.4 Range of operation
Reliable power supply on sailing boats.
3.5 Panda transport box
3.5.1 Bolted Fischer Panda transport box
1. Remove the bolts for cover / sidewalls
2. Remove the cover
3. Remove the loose accessories
4. Remove the bolts for sidewalls / floor pallet
5. Remove the sidewalls
6. Open the generator attachment
3.5.2 Fischer Panda transport box with metal tab closure
1. Bend up the metal tab closures on the transport box lid
2. Remove the cover
3. Remove the loose
4. Bend open the metal tab closures at the bottom of the transport box
5. Remove the sidewalls
6. Open the generator attachment
