Installation Instructions
Seite/Page 74 - Kaptitel/Chapter 6: Installation Instructions 18.12.15
Fig. 6.8.3.0-1: Volume of the waterlock
If there are any doubts, a verification can easily be made by temporarily using a clear-sighted hose (1) as exhaust
hose. In that way, the cooling water level can be checked very easily.
Fig. 6.8.3.0-2: Testing the cooling water level
