9 Measurement
FLUXUS F60* 9.6 Determination of the flow direction
111
UMFLUXUS_F60xV5-0EN, 2017-10-16
9.6 Determination of the flow direction
The flow direction in the pipe can be detected with the help of the displayed volumetric
flow rate in conjunction with the arrow on the transducers:
• The fluid flows in the direction of the arrow if the displayed volumetric flow rate is positive
(e.g., 54.5 m³/h).
• The fluid flows against the arrow direction if the displayed volumetric flow rate is negative
(e.g., -54.5 m³/h).
9.7 Stop of measurement
The measurement is interrupted by pressing key BRK.
Notice!
Be careful not to stop a current measurement by inadvertently pressing key BRK.
