4 Product description
FLUXUS F60* 4.4 Keyboard
29
UMFLUXUS_F60xV5-0EN, 2017-10-16
4.4 Keyboard
The keyboard has 15 keys, including 3 function keys: ENTER, BRK and C.
Some key have multiple functions. They can be used to enter data, to navigate through
scroll lists as well as to execute special functions (e.g., reset of totalizers).
Tab. 4.2: General functions
C switching on the transmitter
LIGHT switching on/off the display backlight
ENTER confirmation of selection or input
BRK + C + ENTER Reset: press these 3 keys simultaneously to correct a malfunction. The
reset has the same effect as a restart of the transmitter. Stored data are
not affected.
BRK interruption of the measurement and selection of the main menu
Be careful not to stop a current measurement by inadvertently pressing
key BRK.
BRK switching off the transmitter by pressing key BRK 3 times
Tab. 4.3: Navigation
BRK selection of the main menu
scroll to the left/right through a scroll list
scroll upwards/downwards through a scroll list
ENTER confirmation of a menu item of the program branch
Tab. 4.4: Input of numbers
… input of the number pictured on the key
sign for the input of negative values
decimal marker
C deletion of values
After the value has been deleted, the previous value will be displayed.
ENTER confirmation of the input
