18.8 Temperature-based heat flow cut-off FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
182
Total digits = Fixed to x digit
The number of decimal points is constant. The max value of the totalizer is reduced with
the number of decimal places.
18.8 Temperature-based heat flow cut-off
With the temperature-based heat flow cut-off, all measured temperature differences be-
tween the supply and return line that are lower than a defined value are set to zero. The
heat flow is also set to zero. The value of the heat quantity totalizer remains unchanged.
• Select Special Funct.\SYSTEM settings\Measuring\Miscellaneous.
• Press ENTER until the menu item Thermal low cut is displayed.
• Select on to activate the temperature-based heat flow cut-off, off to deactivate it.
• Press ENTER.
•If on is selected, enter the limit of the temperature difference. All temperature differenc-
es between the supply and return line that are lower than this value will be set to zero.
Enter zero to work without the temperature-based heat flow cut-off.
• Press ENTER.
decimal places max. value max. display
0< 10
10
±9999999999
1< 10
8
±99999999.9
2< 10
7
±9999999.99
3< 10
6
±999999.999
4< 10
5
±99999.9999
Notice!
The number of decimal places and the max. value defined here only affect the dis-
play of the totalizers.
Special Funct.\SYSTEM settings\Measuring\Miscellaneous\Thermal low cut
Special Funct.\SYSTEM settings\Measuring\Miscellaneous\Thermal
low cut\Thermal flow ->0
