17 Advanced functions
FLUXUS F60* 17.9 Diagnosis by means of the snap function
163
UMFLUXUS_F60xV5-0EN, 2017-10-16
If a measuring channel that is needed for an activated calculation channel has not been
activated, a warning will be displayed.
• Press ENTER.
Position the transducers for all activated measuring channels. The measurement will be
started automatically.
If a calculation channel is activated, the HumanMux mode will be selected at the begin-
ning of the measurement and the values of the calculation channel will be displayed.
If the AutoMux mode is selected, the measured values of the measuring channels will be
displayed alternately (but not the measured values of the calculation channels).
• Press key to display the calculation function.
• Press key to display the measured values of the different channels.
17.9 Diagnosis by means of the snap function
By means of the snap function it is possible to store measuring parameters which are
useful for the evaluation of measuring results or diagnosis purposes.
• Select Special Funct.\SYSTEM settings\Signal snap.
• Press ENTER.
• Select on to activate the snap function. Select off to deactivate the snap function.
• Press ENTER.
• Select Install Snap.
• Press ENTER.
Measuring\...\WARNING! CHANNEL B:INACTIV!
Special Funct.\SYSTEM settings\Signal snap
Special Funct.\SYSTEM settings\Signal snap\DSP-SignalSnap
Special Funct.\...\DSP-SignalSnap\Install Snap
