17 Advanced functions
17.8 Calculation channels FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
162
• Select the unit of measurement.
• Press ENTER.
It is possible to define 2 cut-off flows for each calculation channel. They are defined in the
unit of measurement of the physical quantity selected for the calculation channel.
All positive calculated values less than the limit, will be set to zero.
All negative calculated values that are greater than the limit will be set to zero.
• Enter the damping factor. If the damping factor for the measuring channels A or B has
already been entered in the program branch Output Options, enter the value zero,
see section 9.2.2.
• Press ENTER.
• Select yes to activate the data logger and no to deactivate it.
• Press ENTER.
17.8.4 Measuring with calculation channels
• Select the program branch Measuring.
• Press ENTER.
• Activate the necessary channels. Calculation channels are activated or deactivated the
same way as measuring channels.
• Press ENTER.
Output Options\for Channel Y:\...\Mass in:
Output Options\for Channel Y:\...\+Cut-off Flow
Output Options\for Channel Y:\...\-Cut-off Flow
Output Options\for Channel Y:\...\Damping
Output Options\for Channel Y:\...\Store Meas.Data
Measuring\CHANN: A B Y Z
