14 Inputs
FLUXUS F60* 14.1 Assignment of the temperature inputs to the measuring channels
129
UMFLUXUS_F60xV5-0EN, 2017-10-16
14 Inputs
External transducers can be connected to the inputs (optional) in order to measure the
following physical quantities:
• temperature
• density
• pressure
• kinematic viscosity
• dynamic viscosity
The values of the current, voltage and temperature inputs can be used by all measuring
channels.
An input has to be assigned to a measuring channel and activated before it can be used
for the measurement and for the storing of measured values.
• Select Special Funct.\SYSTEM settings\Proc. inputs.
• Press ENTER.
Depending on the configuration of the transmitter, one or several of the following list
items will be displayed:
14.1 Assignment of the temperature inputs to the measuring
channels
For the assignment of the temperature inputs during the heat flow measurement see
chapter 21.
• Select Special Funct.\SYSTEM settings\Proc. inputs.
• Press ENTER.
Special Funct.\SYSTEM settings\Proc. inputs
Tab. 14.1: List items for Proc. inputs
list item function
Link temperature assignment of temperature inputs to measuring channels
Link other inp. assignment of other inputs to measuring channels
PT100/PT1000 selection of a temperature probe
...go back return to the previous menu item
Special Funct.\SYSTEM settings\Proc. inputs
