Page #130 background imageLoading...
Page #130 background image
14 Inputs
14.1 Assignment of the temperature inputs to the measuring channels FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
130
Select Special Funct.\SYSTEM settings\Proc. inputs.
Press ENTER until the menu item T-Fluid/Outle. is displayed.
Select the temperature input to be assigned to measuring channel A as fluid tempera-
ture. The temperature value will be used for the calculation of the selected physical
quantity.
Select the list item Fixed input val.if the temperature is to be entered manually
before the measurement.
Select the list item No measuring if no temperature is to be assigned to measuring
channel A.
Press ENTER.
Enter the list items T(3)and T(4)if additional temperature values besides the fluid
temperature are to be measured and stored. These additional temperature values will
not be used for the calculation of the selected physical quantity.
Repeat the steps for the other activated channels accordingly.
Press ENTER after each input.
Selection of the temperature probe
Select Special Funct.\SYSTEM settings\Proc. inputs.
Press ENTER.
Select the list item PT100/PT1000.
Press ENTER.
Special Funct.\SYSTEM settings\Proc. inputs\Link temperature
Special Funct.\SYSTEM settings\...\Link temperature\T-Fluid/
Outle.\Input T1
Notice!
The configuration of a measuring channel will be stored when the next channel is
selected. The configuration dialog for a channel has to be completed in order to
store the changes.
Special Funct.\SYSTEM settings\Proc. inputs
Special Funct.\SYSTEM settings\Proc. inputs\PT100/PT1000
