20 Wall thickness measurement (optional)
FLUXUS F60* 20.4 Measurement
201
UMFLUXUS_F60xV5-0EN, 2017-10-16
20.3.2 Parameter input for the sound speed measurement
The thickness of the pipe has to be entered to determine the longitudinal sound speed of
a material.
• Select in
Output Options\Physic. Quant.
the physical quantity
c-LONGITUDINAL
for the measuring channel to which the wall thickness probe is connected.
• Select Parameter\Wall Thickness.
• Enter the pipe wall thickness.
20.4 Measurement
• Select in the main menu the program branch Measuring.
• Press ENTER.
This error message will be displayed if the entered parameters are not complete.
20.4.1 Measurement of the wall thickness
This display is indicated if the wall thickness is selected as the physical quantity for the
measuring channel connected to the probe.
As long as there is no valid measured value, the unit of measurement and a question
mark will be displayed in the lower line.
• Apply a thin film of the coupling compound to the pipe wall.
• Press the wall thickness probe against the pipe wall in this position.
Output Options\Physic. Quant.\c-LONGITUDINAL
Parameter\Wall Thickness
Measuring
Measuring\NO DATA!
