13 Outputs
FLUXUS F60* 13.4 Activation of a binary output as pulse output
127
UMFLUXUS_F60xV5-0EN, 2017-10-16
13.4 Activation of a binary output as pulse output
A pulse output is an integrating output which emits a pulse when the volume or the mass
of the fluid which has passed the measuring point reaches a given value (
Pulse Value
).
The integrated quantity is the selected physical quantity. Integration is restarted as soon
as a pulse is emitted.
• Select the channel for which the output is to be activated in the program branch
Output
Options
.
• Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
• Press ENTER until Pulse Output is displayed. Select yes to activate the output.
• Press ENTER.
This error message will be displayed if the flow velocity is selected as the physical quantity.
The use of the pulse output is not possible in this case because the integration of the flow
velocity does not result in a reasonable value.
• Enter the pulse value. The unit of measurement will be displayed according to the actual
physical quantity.
When the counted physical quantity reaches the entered pulse value, a pulse will be
transmitted.
• Press ENTER.
The menu item
Pulse Output
will only be indicated in the program branch
Output
Options
if a pulse output has been installed.
Output Options\for Channel A:
Output Options\...\Pulse Output
Output Options\...\Pulse Output\NO COUNTING
Output Options\...\Pulse Output\Pulse Value
