13 Outputs
13.3 Configuration of a frequency output as pulse output FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
126
• Enter the upper limit of the frequency.
• Press ENTER.
The lower limit of the frequency and the error value will be set automatically to 0.5 Hz.
Activation of a frequency output
• Select the channel for which the output is to be activated in the program branch
Output
Options
.
• Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
• Press ENTER until
Frequency Output
is displayed. Select
yes
to activate the output.
• Press ENTER.
• Enter the number of pulses that is to be assigned to the unit of measurement of the
totalizer.
• Press ENTER.
Example: 1000 pulses correspond to 1 m³ of the totalized fluid.
The max. flow depending on the upper limit of the frequency and pulse value is indicated.
• Press ENTER.
Special Funct.\SYSTEM settings\Proc. outputs\...\F1 Output MAX
Output Options\for Channel A:
Output Options\...\Frequency Output
Output Options\...\Frequency Output\Pulses per unit
Output Options\...\Frequency Output\INFO: max flow= 3600.0 m3/h
To Next Page
