16 Data transmission
16.6 Offline transmission of data to a terminal program FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
146
16.6 Offline transmission of data to a terminal program
• Start the terminal program.
• Enter the transmission parameters into the terminal program, see section 16.4. The
transmission parameters of the terminal program and the transmitter have to be identical.
• Select Special Funct.\Print Meas.Val.
• Press ENTER.
The message NO VALUES will be indicated if no measured valued are stored.
• Press ENTER.
The message Send Header will be displayed if the measurement values are transmitted.
The progress of the transmission of data is displayed by a bar graph.
The message SERIAL ERROR will be displayed if an error has occurred during the serial
transmission.
• Press ENTER.
• Check the connections and make sure the PC is ready to receive data.
16.7 Data structure
First, the header is transmitted. The first 4 lines contain general information about the
transmitter and the measurement. The following lines contain the parameters for each
channel.
Special Funct.\Print Meas.Val.
