13 Outputs
13.2 Installation of a binary output FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
122
Zero-Scale Val. is the value assigned to the value Output MIN of the output range.
• Enter the value 0.00. The unit of measurement of the source item will be displayed.
• Press ENTER.
Full-Scale Val. is the value assigned to the value Output MAX of the output range.
• Enter the value 0.01.
• Press ENTER.
In addition to the analog outputs, the transmitter can also be equipped with binary and
frequency outputs.
13.2 Installation of a binary output
If the transmitter is equipped with binary outputs, they have to be installed and activated
before they can be used:
• assignment of a measuring channel (source channel) to the binary output (if the trans-
mitter has more than one measuring channel)
• assignment of the physical quantity (source item) to be transmitted to the output by the
source channel, and the properties of the signal
• activation of the installed binary output in the program branch Output Options
• Select Special Funct.\SYSTEM settings\Proc. outputs.
• Press ENTER.
Output Options\...\Zero-Scale Val.
Output Options\...\Full-Scale Val.
If the output P1 is not used, the outputs P1 and P2 should be deactivated in order to
obtain maximum battery performance.
The settings will be stored at the end of the dialog. If the menu item is quit by press-
ing key BRK, the changes will not be stored.
Special Funct.\SYSTEM settings\Proc. outputs
