Flexim FLUXUS F60 Series User Manual

14 Inputs
FLUXUS F60* 14.2 Assignment of other inputs to the measuring channels
131
UMFLUXUS_F60xV5-0EN, 2017-10-16
• Select the temperature probe.
• Press ENTER.
• If necessary, select the temperature probe for Input T2...T4 accordingly.
14.2 Assignment of other inputs to the measuring channels
• Select Special Funct.\SYSTEM settings\Proc. inputs.
• Press ENTER.
• Select the list item Link other inp.
• Press ENTER.
• Select the first input to be assigned to measuring channel A. Only the installed inputs
are displayed in the scroll list.
• Select the list item No measuring if no input is to be assigned to measuring channel A.
• Press ENTER.
Select the list items for ext.Input(2)...(4) of the measuring channel A and the other
activated channels accordingly.
Special Funct.\SYSTEM settings\...\Input T1
Special Funct.\SYSTEM settings\Proc. inputs
Special Funct.\SYSTEM settings\Proc. inputs\Link other inp.
Special Funct.\SYSTEM settings\...\A:ext.Input(1)\Input I1
Notice!
The configuration of a measuring channel will be stored when the next channel is
selected. The configuration dialog for a channel has to be completed in order to
store the changes.
