FLUXUS F60* 13.3 Configuration of a frequency output as pulse output
125
UMFLUXUS_F60xV5-0EN, 2017-10-16
13.3 Configuration of a frequency output as pulse output
A frequency output sends a signal with a frequency that depends on the volumetric flow
rate. The frequency output can be configured in such way that the source item can be
totalized by using each period of the output signal as the increment.
Installation of a frequency output (optional)
• Select the frequency output to be installed.
• Press ENTER.
• Select yes to install or reconfigure the output.
• Press ENTER.
• Select no to uninstall the output and to return to the previous menu item in order to
select another output.
• Press ENTER.
• Select the measuring channel to be assigned to the frequency output as the source
channel in the scroll list.
• Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
• Select as source item Measuring value in the scroll list (but not Impuls).
• Press ENTER.
If Measuring value is selected and the source item can be totalized, a request will be
indicated whether the frequency output is to be configured as a pulse output.
• Select yes.
• Press ENTER.
Special Funct.\SYSTEM settings\Proc. outputs\Install Output
Special Funct.\SYSTEM settings\Proc. outputs\F1 enable
Special Funct.\SYSTEM settings\Proc. outputs\...\F1 Source chan.
Special Funct.\SYSTEM settings\Proc. outputs\...\Source item\
Measuring value
Special Funct.\SYSTEM settings\Proc. outputs\...\Setup as pulse ?
