13 Outputs
13.2 Installation of a binary output FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
124
Function test of the binary output
The function of the output can now be tested.
• Connect an external measuring instrument to the terminals of the output.
• Select Reed-Relay OFF or Open collect OFF in the scroll list Output Test to
test the de-energized state of the output.
• Press ENTER. Measure the resistance at the output. The value has to be high ohmic.
• Select yes to repeat the test, no to return to the menu item SYSTEM settings.
• Press ENTER.
• Select Reed-Relay ON or Open collect. ON in the scroll list Output Test to test
the energized state of the output.
• Press ENTER. Measure the resistance at the output. The value has to be low ohmic.
• Select yes to repeat the test, no to return to the menu item SYSTEM settings.
• Press ENTER.
Tab. 13.1: Configuration of the binary outputs
source item list item output
Limit R1 limit message (Alarm Output R1)
R2 limit message (Alarm Output R2)
R3 limit message (Alarm Output R3)
Impuls from abs(x) pulse without sign consideration
from x > 0 pulse for positive measured values of the volumetric flow rate
from x < 0 pulse for negative measured values for the volumetric flow rate
Special Funct.\SYSTEM settings\Proc. outputs\...\B1 Output Test\
Reed-Relay OFF
Special Funct.\...\B1 Output Test\B1=ON\Again?
Special Funct.\SYSTEM settings\Proc. outputs\...\B1 Output Test\
Reed-Relay ON
Special Funct.\...\B1 Output Test\B1=ON\Again?
