Flexim FLUXUS F60 Series User Manual

Annex
A Menu structure FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
228
Alarm output
(see chapter 17)
Main menu
Special Funct.
SYSTEM settings
Proc. outputs
Install Output
Main menu
→ Binary
enable Output Options
Source chan. for Channel …
Source item ENTER until
→ Limit Alarm Output
func typ mode
→ MAX
→ MIN
→ QUANT. → +→- -→+
→ ERROR
→ OFF
→ NON-HOLD
→ HOLD
→ NO Cont.
→ NC Cont.
R1 Input Quantity Limit:
→ Volume flow
→ Signal amplitude
→ c-Medium
→ SCNR
High Limit:
R1 Hysterese
Display of the set alarm
state
1
2
