7 Connection
7.1 FLUXUS *601 FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
56
7.1.4.3 Input adapter
The number of temperature inputs can be increased to max. 4 by means of 2 input adapt-
ers (optional), see Fig. 7.7.
If the transmitter has voltage or current inputs, the adapter for voltage and current inputs
will be used, see Fig. 7.8.
Fig. 7.7: Connection of the input adapters
1 input adapter
CH A
COMM
Output
P3...P8
P2 P1
T1/T3 T2/T4
Input
CH B
DC-IN
1
T1 T2
T3 T4
