7 Connection
7.2 FLUXUS *608 FLUXUS F60*
2017-10-16, UMFLUXUSF60xV5-0EN
62
Fig. 7.14: Connection of the transducers to the transmitter
1 – transducers (measuring channel A)
2 – transducers (measuring channel B)
Fig. 7.15: Transducer connection
Fig. 7.16: Transducer connection
1 – transducer connector
2 – locking ring
3 – locking screw
CH A
COMM
CH B
DC-IN
1
2
(a)
(b)
1
2
3
