10 Measurement
10.3 Measurement settings PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
110
Tab. 10.1: Configuration of the outputs
source item list item output
Flow/analysis Mass fraction physical quantity for analysis selected in the program branch Parameters
(here: Mass fraction)
Flow velocity flow velocity
Volumetric flow
rate
volumetric flow rate
Mass flow rate mass flow rate
Totalizers Volume (+) totalizer for the volumetric flow rate in positive flow direction
Volume (-) totalizer for the volumetric flow rate in negative flow direction
Volume (Δ) difference of the totalizers for the positive and negative flow direction
Mass (+) totalizer for the mass flow rate in positive flow direction
Mass (-) totalizer for the mass flow rate in negative flow direction
Mass (Δ) difference of the totalizers for the positive and negative flow direction
Pulse Pulse |V| pulse without sign consideration of the volumetric flow rate
Pulse +V pulse for positive measured values of the volumetric flow rate
Pulse -V pulse for negative measured values for the volumetric flow rate
Pulse |m| pulse without sign consideration of the mass flow rate
Pulse +m pulse for the positive measured values of the mass flow rate
Pulse -m pulse for the negative measured values of the mas flow rate
Fluid properties Fluid temp. fluid temperature
Fluid pressure fluid pressure
Fluid density fluid density
Kin. viscosity kinematic viscosity
Dyn. viscosity dynamic viscosity
Norm. density standardized density
Event trigger R1 limit message (Event trigger R1)
R2 limit message (Event trigger R2)
R3 limit message (Event trigger R3)
R4 limit message (Event trigger R4)
Diagnostic values Amplitude signal amplitude
Quality signal quality
SNR ratio useful signal/noise signal
SCNR ratio of useful signal and correlated noise signal
VariAmp amplitude fluctuation
VariTime transit time fluctuation
Amplification amplification, important to receive a useful signal
Pig detection signalizes whether a pig is detected
This display will only be indicated if Pig detection is activated.
