10 Measurement
PIOX S72* 10.3 Measurement settings
115
UMPIOX_S72xV1-9EN, 2022-05-15
Terminal assignment
The terminals for the connection of the output are displayed.
By pressing or further information is displayed.
• Press ENTER.
Output function test
The function of the output can now be tested.
• Connect an external measuring instrument to the terminals of the output.
•Select Yes to test the output. Select No to display the next menu item.
• Press ENTER.
• Enter a test value. It has to be within the output range.
• Press ENTER.
If the external measuring instrument displays the entered value, the output functions correctly.
•Select Repeat to repeat the test, Finish to display the next menu item.
• Press ENTER.
•Select Yes to test the status of the output signal. Select No to display the next menu item.
• Press ENTER.
• Select a list item as test value.
• Press ENTER.
•Select Repeat to repeat the test. Select Finish to display the next menu item.
• Press ENTER.
• Press and hold to return to the main menu.
status value – status OK event value – idle state
The status of the output signal is defined which is to be output
when measuring a measured value.
The status of the output signal is defined which is to be output if
no event occurs.
• Select the value for Status OK from the scroll list.
•Press ENTER.
• Select the value for the idle state.
•Press ENTER.
Options\Channel A\Outputs\...\Output info
Options\Channel A\Outputs\...\Test signal
Options\Channel A\Outputs\...\Enter test value
Options\Channel A\Outputs\...\Test mea. range
Options\Channel A\Outputs\...\Enter test value
status value event value
Status OK or Status error
If the external measuring instrument displays the value (min.
output value for Status error, max. output for Status OK),
the output functions correctly.
Active or Passive
If the external measuring instrument displays the value (min.
output value for Passive, max. output for Active), the output
functions correctly.
