10 Measurement
10.3 Measurement settings PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
114
Output function test
The function of the output can now be tested.
Connect an external measuring instrument to the terminals of the output.
•Select Yes to test the output. Select No to display the next menu item.
Press ENTER.
Enter a test value. It has to be within the output range.
Press ENTER.
If the external measuring instrument displays the entered value, the output functions correctly.
•Select Repeat to repeat the test, Finish to display the next menu item.
Press ENTER.
•Select Yes to test the assignment of the measured value to the output signal. Select No to display the next menu item.
Press ENTER.
Select in the scroll list Active or Passive.
Press ENTER.
If the external measuring instrument displays the value (min. output value for Passive, max. output for Active), the
output functions correctly.
•Select Repeat to repeat the test. Select Finish to display the next menu item.
Press ENTER.
10.3.6.2 Output of a status/event value
Select the list item
Options\Channel A\Outputs\...\Status.
Press ENTER.
Output range
Select a list item.
4...20 mA
Other range
Press ENTER.
If Other range is selected, enter the values Output
MIN and Output MAX.
The output range has to be > 10 % of the max. output value (Output MAX). If the output range is smaller, an error
message will be displayed. The next possible value will be displayed.
Options\Channel A\Outputs\...\Test signal
Options\Channel A\Outputs\...\Enter test value
Options\Channel A\Outputs\...\Test mea. range
Options\Channel A\Outputs\...\Enter test value
Source item
Status
Output range
Status OK Idle state
Output info
Test signal
Test mea. range
see annex A
Options\Channel A\Outputs\...\
Output range
