16 Outputs (TF7-*72***-******-******a-*****-**; a = M, P, Q)
PIOX S72* 16.2 Configuration of a digital output as pulse output
157
UMPIOX_S72xV1-9EN, 2022-05-15
16.2.2 Pulse output by defining pulses per unit
•Select Pulses per unit.
• Press ENTER.
• Select a list item:
– 0...1 kHz
– 0...5 kHz
– Other range
• Press ENTER.
If Other range is selected, enter a value for Output MAX.
• Enter the number of pulses per unit.
• Press ENTER.
The unit of measurement will be displayed according to the actual physical quantity.
16.2.3 Output options
• Select the setting of the idle state:
Terminal assignment
The terminals for the connection of the output are displayed.
By pressing or further information is displayed.
• Press ENTER.
Output function test
•Select Yes to test the status of the output signal. Select No to display the next menu item.
• Press ENTER.
• Select a list item as test value.
• Press ENTER.
Options\Channel A\Outputs\Digital output B1\Source item\Pulse\Pulse output
Options\Channel A\Outputs\Digital output B1\...\Output range B1
Options\Channel A\Outputs\Digital output B1\...\Pulses per unit
Options\Channel A\Outputs\Digital output B1\Source item\Pulse\...\Idle state
setting description
NO The pulse output is energized if a pulse is emitted and de-energized if no pulse is emitted (idle
state).
NC The pulse output is de-energized if a pulse is emitted and energized if no pulse is emitted (idle
state).
Options\Channel A\Outputs\Digital output B1\...\Output info
Options\Channel A\Outputs\...\B1 Test signal
Options\Channel A\Outputs\...\B1 Enter test value
