Configuration and Operation
41
Quasar CP-6302 Range User Guide - Ver. 8 - January 31, 2021
Detection Switch
The Administrator can select from the following options:
·
Select Off to disable audio (default setting).
·
Select On to enable audio.
·
Select By Schedule to set a schedule. Then click Please Select to select up to 10 schedules from
the drop-down list that opens. The selected schedules are displayed in the Please Select text
box. To set a schedule, open the Schedule tab.
Click SAVE after configuring the settings.
Audio Detection Setting
Set the Detection Level and Time Interval for detecting audio.
·
Set Detection Level – Setting a low threshold (for example, 25) means that the camera is more
sensitive to noise, which results in more alerts (displayed in red). The setting depends on the
situation and environment. If the scene is located in a quiet place, it is possible to use lower
threshold. A noisy location requires a higher threshold.
Triggered Action
The Administrator can specify various alarm actions to take when an alarm is triggered. See the
Triggered Actions section for a detailed description of the actions. The following options are available:
·
Enable alarm output 1 – Check this box and select the predefined type of alarm output (low or
high) to enable alarm relay when a network failure is detected.
·
Enable alarm output 2 – Check this box and select the predefined type of alarm output (low or
high) to enable alarm relay when a network failure is detected.
·
Send message by FTP – Select whether to send an alarm message by FTP when a network
failure is detected.
·
Send message by E-Mail – Select whether to send an alarm message by e-mail when an audio
event is detected.
·
Upload Image by FTP – Selecting this option enables you to assign an FTP site and configure
various parameters.
·
Upload image by E-Mail – Select this box in order to assign an e-mail address and configure
various parameters.
·
Send HTTP notification – Select this checkbox to send a notification by HTTP.
·
Record video clip – Select this box in order to save the alarm-triggered recording to your
microSD/SDXC card or to the NAS.
Click SAVE after configuring the settings.
File Name
·
File Name – Enter a file name in the field, for example image.jpg. The uploaded image’s file
name format is set in this section. Select one that meets your requirements.
·
Add date/time suffix (default setting)
File name: imageYYMMDD_HHNNSS_XX.jpg
Y: Year, M: Month, D: Day
H: Hour, N: Minute, S: Second
X: Sequence Number
