Quasar CP-6302 Range User Guide - Ver. 8 - January 31, 2021
·
*Light On – Activates IR mode (puts camera into monochrome/Night mode). The IR LEDs are
continuously illuminated.
·
*Light Off – Deactivates IR mode (puts camera into color/Day mode). The IR LEDs are
continuously off.
·
Smart – Smart mode enhances monochrome/Night mode stability and keeps the camera from
switching between Day and Night modes. In this mode, when IR illumination is dominant, the
camera decides when to remove the IR Cut filter.
On the 31-I IR model, when the IR Cut filter is on (i.e. monochrome/Night mode), the IR LED
illuminator also is activated. This prevents the camera from returning to color/Day mode.
Note:
When video transitions from day-to-night and night-to-day it may appear off-color. This should be
resolved within a few seconds as the levels of light decrease or increase, respectively.
Day/Night Threshold
Set the threshold at which you want to activate the IR function. The setting is applied automatically.
·
For the daytime to nighttime threshold , from the drop-down list, select a number between 1-9,
where 1 is darker and 9 is brighter, or select Darker or Brighter. The default setting is 7.
·
For the nighttime to daytime threshold , from the drop-down list, select a number between 1-9,
where 1 is darker and 9 is brighter, or select Darker or Brighter. The default setting is 3.
IR Compensation
From the drop-down list, set the IR Compensation to On or Off. Setting IR Compensation to On
compensates for the reflection of infrared light emitted from the camera onto reflective objects, thus
improving image sharpness and definition. Without IR compensation, objects may appear blurred. The
default setting is On. The setting is applied automatically.
IR Heating (Available on CP-6302-31-I only)
*IR Heating allows control over the internal temperature of the camera. Off by default.
When set to On, the camera will maintain operational temperature in particularly cold surroundings.
Note:
1. It is recommended that this feature only be used in conditions of extreme cold.
2. The camera must have a Zoom MCU version of T2-L34-I0-180724-02 to support this feature.
Please contact FLIR Support to download this file
