FLIR Quasar Gen III CP-6302 Series - Quad-Stream Video Configuration; Quad-Stream Resolution Combinations

This document does not contain any export-controlled information.
Configuration and Operation
69
Quasar CP-6302 Range User Guide - Ver. 8 - January 31, 2021
H.265/H.264/MJPEG + H.265/H.264/MJPEG + H.265/H.264/MJPEG
Stream 1
Stream 2
Stream 3
720 x 576 (PAL)
720 x 480 (NTSC)
1920 x 1080
1920x1080 - 320x240
1280 x 1024
1024 x 768
800 x 600
720 x 576 (PAL)
720 x 480 (NTSC)
640 x 480
352 x 288 (PAL)
352 x 240 (NTSC)
320 x 240
640 x 480
1920 x 1080
1920x1080 - 320x240
1280 x 1024
1024 x 768
800 x 600
720 x 576 (PAL)
720 x 480 (NTSC)
640 x 480
352 x 288 (PAL)
352 x 240 (NTSC)
320 x 240
5.5.1.1.6 Quad-Stream
From the Resolution drop-down menu, select the desired resolution. A maximum 25/30 frames per
seconds (PAL/NTSC) is available when selecting WDR 2 Shutter (PAL) or WDR 2 Shutter (NTSC). A
maximum 50/60 frames per second (PAL/NTSC) is available when selecting 50 fps (PAL) or 60 fps
(NTSC). The default setting is 1920 x 1080.
Note:
The default bit rate for Stream 1 and Stream 2 is 4096 bps. The default bit rate for Stream 3 and
Stream 4 is 2048 bps.
