Configuration and Operation
93
Quasar CP-6302 Range User Guide - Ver. 8 - January 31, 2021
5.7.7 Privacy Mask
From the Privacy Mask page, you can set up to 20 privacy masks. The Privacy Mask function allows
concealment of sensitive portions of the camera image to avoid intrusive monitoring.
Note:
1. The Flip function on the PTZ Setting screen is automatically disabled when the Privacy Mask
function is on.
2. The Zoom Factor function is disabled when the Stabilizer is set to Off on the Camera > Misc.
screen.
Privacy Mask Screen
To create a mask
1. From the Switch drop-down menu, select On to activate or Off to disable the Privacy Mask
function.
2. Click SET to save the setting.
3. From the Color drop-down menu, select the desired color for the specified Privacy Mask.
4. Click SET to save the setting.
5. In the Mask text box, it is possible to create up to 20 masks. Enter the number (1-20) of the
programmed Privacy Mask.
6. From the Zoom Factor drop-down menu, select On or Off. If the Zoom Factor is set to lower than
20x and the object is very small, a privacy mask will not be displayed. When Zoom Factor is On, the
mask is displayed with 20x zoom and higher.
7. Click ADD to save the programmed Privacy Mask.
8. To edit a programmed Privacy Mask, select the Privacy Mask and click EDIT.
To clear (delete) an existing Privacy Mask
1. From the Mask drop-down menu, select the Privacy Mask.
2. Click CLEAR.
5.7.8 PTZ Setting
The PTZ Setting screen includes a few miscellaneous settings.
PTZ Setting Screen
