Configuration and Operation
61
Quasar CP-6302 Range User Guide - Ver. 8 - January 31, 2021
Note:
1. The performance on Streams 2, 3, and 4 depends on the combination and settings of
each stream configured before it. For example, Stream 4 performance depends on the
settings for Streams 1, 2, and 3. Stream 3 performance depends on the settings for
Streams 1 and 2.
2. The maximum frame rate on Streams 2, 3, and 4 also depends on the selection of WDR
2 Shutter (PAL) or WDR 2 Shutter (NTSC) for maximum 25/30 frames per second, or
50 fps (PAL) or 60 fps (NTSC) for maximum 50/60 frames per second from the Camera
> Misc. screen.
3. Images can be sent by FTP or email only when MJPEG steaming is selected as one of
the streams.
4. United VMS supports only three streams.
5.5.1.1.1 Single-Stream H.265
To implement single-stream H.265 compression
1. In the Stream 1 section, from the Encode Type drop-down menu, select H.265. The section
expands. The following options are available if you select CBR Rate Control:
H.264/H.265 with CBR Rate Control
The following options are available if you select VBR Rate Control:
H.264/H.265 with VBR Rate Control
The following options are available if you select LBR Rate Control and disable Dynamic GOV:
H.264/H.265 with LBR Rate Control
The following options are available if you select LBR Rate Control and enable Dynamic GOV:
H.264/H.265 with LBR Rate Control and Dynamic GOV
