Configuration and Operation
64
Quasar CP-6302 Range User Guide - Ver. 8 - January 31, 2021
Note:
Images can be sent by FTP or email only when MJPEG steaming is selected as one of the
streams.
5.5.1.1.4 Dual-Stream
From the Resolution drop-down menu, select the desired resolution. A maximum 25/30 frames per
seconds is available when selecting WDR 2 Shutter (PAL) or WDR 2 Shutter (NTSC). A maximum 50/60
frames per second is available when selecting 50 fps (PAL) or 60 fps (NTSC). The default setting is 1920
x 1080.
Note:
An analog video output is supported in dual-stream mode on 1920 x 1080 when the second stream is
D1 or lower.
H.265/H.264/MJPEG + H.265/H.264/MJPEG
Stream 1
Stream 2
1920 x 1080
1920 x 1080
1280 x 1024
1280 x 720
1024 x 768
800 x 600
720 x 576 (PAL)
720 x 480 (NTSC)
640 x 480
352 x 288 (PAL)
352 x 240 (NTSC)
320 x 240
