Min Shutter Speed – When selecting this mode, the shutter is completely open and the exposure
priority is given to the iris. Shutter speed and AGC circuit function automatically in cooperating
with the iris to achieve a consistent exposure output.
The following table lists the options:
Iris Priority
Min Shutter Speed
5.6.1.4 Auto Shutter Mode
Auto Shutter mode is the default. Auto Shutter mode opens the shutter completely. Shutter speed and the
AGC circuit function automatically in cooperating with the iris to achieve a consistent exposure output.
The exposure priority is given to the iris. This mode is recommended to be used in indoor environments
involving mixed lighting sources where the main source is fluorescent lighting combined with natural light
that enters the scene through windows and other exposed areas.
In the Exposure section, configure the following settings:
·
Min Shutter Speed – Select a suitable shutter speed according to the environmental luminance.
The following table displays the options:
Auto Shutter
Min Shutter Speed
5.6.1.5 Shutter Priority Mode
Shutter Priority mode is used to set a fixed exposure while other parameters can change. Continue to
configure the settings in the Exposure section:
To Next Page
