Configuration and Operation
46
Quasar CP-6302 Range User Guide - Ver. 8 - January 31, 2021
Disk Cleanup Setting
Enable automatic recording cleanup by selecting Enable automatic disk cleanup. From the pull-down
menu, specify the minimum length of time over which to remove recordings. For example, remove
recordings over 10 days old. Enter the percent of disk capacity used in order to remove the oldest
recordings. Click SAVE when finished.
Recording List
Each video file on the microSDXC card is listed in the Recording List table below. The maximum file size
is 60 MB per file. See Recording for further details.
When the recording mode in the Recording screen is set as Always (consecutive recording) and the
microSD/SDXC card recording is enabled by events triggered, the system immediately saves a recorded
event on the memory card once an event occurs. The camera then returns to the regular recording mode
after events recording.
Video Clip Recording List
·
Remove – To remove a file, first select the file and then click REMOVE.
·
Sort – Click SORT to list the files in the Recording List table in order of name and date.
Note:
The capital letters: R, N, A, (A0), M, (M0) followed by an underscore, appear at the beginning
of the file name. They denote the type of recording.
·
R - Regular (always or schedule)
·
N - Network failure
·
M - Motion, (M0 refers to the first motion window trigger)
·
A - Alarm (A0 refers to the first alarm trigger input).
·
Download – To open/download a video clip, first select the file and then click DOWNLOAD. The
selected file window pops up as shown below. Click the AVI file to play the video in the player or
download it to a specified location.
Selected File Window
