5322A
Operators Manual
202
Fluke 5322A
DUT
Fluke 5322A-LOAD
Jumper
iep198.eps
Figure 59. Class I Flash Leakage Current Measurement
XWWarning
To prevent possible electrical shock, fire, or personal injury, do
not use the 5322A-LOAD for Flash Class II leakage current
tests. A Flash Class II leakage current test requires a load that
can be floated to 1.5 kV above earth ground. The 5322A-LOAD
has a 20 V peak limit.
